Description
The EmStat4M Development Kit is equipped with a research-grade potentiostat module, which delivers desktop performance. The EmStat4M is a potentiostat/galvanostat supporting Electrochemical Impedance Spectroscopy (EIS). The EmStat4M Development Kit can be used with PSTrace for Windows. You can write your own applications for the EmStat4M Development Kit using our .NET libraries for Windows and Android or using MethodSCRIPT™ and control it from any platform or operating system like an Arduino.
Versions
The EmStat4M Development Kit comes with two different versions of the EmStat4M potentiostat module:
- Low Range (LR): current range from 1 nA to 10 mA, max. 30 mA
- High Range (HR): current ranges from 100 nA to 100 mA, max. 200 mA
Included in the EmStat4M Development Kit
The Development kit includes a sensor cable, software, a Development Board (PCBA) and more. The Development Board offers extra peripherals including:
- Wireless communication module (Laird BT900)
- Support for a LiPo battery, incl. charging
- Pin headers for an MKR-series Arduino
- Break-out EmStat4M GPIO pins for easy connection
- Screw-terminals for easy wire connections
- I2C real-time clock (RTC)
- and push buttons for triggering / testing
